业务场景：在数据量庞大的折叠折线图中，给其中一条添加两条水平的标线，标线的Y轴用户自定义，起点标记的图形用设计好的两个png小图片。
需求分析：方案一：使用图例，也就是重新画一条折线图，折线图的x轴对应相同的一个y轴值，并设置虚线，但是起始图标是个问题，该方案不可行。
方案二：使用折线图的 markline
，markline.data中放两个对象，一个对象表示一条水平线，markline.data.0.symbol
设置水平线的起始图标注意：这里不能直接导入静态的png图片,Echarts不能直接识别；
我的做法是将png上传到官方
示例，官方示例会将你上传的png转换成 symbol:
的图片，把它copy下来，放到你的项目中；
实现过程：
<div id="demo">
<!-- 折线图 -->
<div style="height: 496px; border: 1px solid #ebeef5;">
<v-chart id="performanceChart" :options="performanceOption" style="width: 100%; height: 100%;" />
</div>
</div>// 引包的代码我省略了，不是本文的重点
this.performanceOption = {
title: {
text: "数据准备中",
left: "center",
top: "center",
textStyle: {
fontSize: 16,
fontWeight: 400
}
},
legend: [
{
data: legends,
top: "2%",
left: "25%",
right: "10%",
selected: this.selectedLegend
},
{
data: ["数据4"],
top: "73%",
right: "0%"
}
],
dataZoom: [
{
id: "dataZoomX",
type: "slider",
xAxisIndex: [0, 1],
height: 20,
top: "65%",
right: 10,
left: 10,
handleIcon:
"M10.7,11.9v-1.3H9.3v1.3c-4.9,0.3-8.8,4.4-8.8,9.4c0,5,3.9,9.1,8.8,9.4v1.3h1.3v-1.3c4.9-0.3,8.8-4.4,8.8-9.4C19.5,16.3,15.6,12.2,10.7,11.9z M13.3,24.4H6.7V23h6.6V24.4z M13.3,19.6H6.7v-1.4h6.6V19.6z",
handleSize: "80%",
fillerColor: "rgba(255, 76, 31,.2)",
dataBackground: {
areaStyle: {
color: ""
},
lineStyle: {
opacity: 1,
color: "#FF4C1F"
}
},
handleStyle: {
color: "#FF4C1F"
},
filterMode: "weakFilter",
zoomOnMouseWheel: "false"
}
],
tooltip: {
trigger: "axis",
axisPointer: { type: "cross" },
formatter: function (datas) {
let res = datas[0].name + "<br/>";
let length = datas.length;
let i = 0;
for (; i < length; i++) {
res += `
<span style="display:inline-block;margin-right:5px;border-radius:10px;width:10px;height:10px;background-color:${datas[i].color
};"></span>
${datas[i].seriesName}: ${datas[i].value != null ? datas[i].value.toFixed(4) : "无数据"
}
<br/>
`;
}
return res;
}
},
axisPointer: {
// 坐标轴指示器
link: { xAxisIndex: "all" },
label: { backgroundColor: "#777" }
},
grid: [
{
top: 40,
left: 10,
right: 0,
bottom: 20,
height: "60%"
},
{
left: 10,
right: 0,
bottom: 15,
height: "20%"
}
],
xAxis: [
{
type: "category",
data: dts,
axisLine: {
show: true,
lineStyle: {
color: "#D8D8D8"
}
},
axisTick: {
show: false
},
axisLabel: {
show: true,
textStyle: {
fontSize: 10,
color: "#222831"
}
},
splitLine: {
show: false
},
scale: true
},
{
type: "category",
gridIndex: 1,
data: dts,
axisLine: {
lineStyle: {
color: "#D8D8D8"
}
},
scale: true,
axisTick: { show: false },
splitLine: { show: false },
axisLabel: { show: false }
}
],
yAxis: [
{
scale: true,
splitArea: {
show: false
},
splitNumber: 4,
axisLabel: {
show: true,
textStyle: {
fontSize: 10,
color: "#808080",
align: "left"
}
},
axisLine: {
show: false,
lineStyle: {
color: "#D8D8D8"
}
},
axisTick: {
show: false
},
splitLine: {
show: true,
lineStyle: {
color: "#F5F5F5"
}
}
},
{
type: "value",
gridIndex: 1,
offset: -10,
axisLabel: {
show: true,
textStyle: { fontSize: 10, color: "#808080", align: "left" }
},
axisLine: { show: false },
axisTick: { show: false },
splitLine: { show: false }
}
],
series: [
...simulation, // 数据3
...fund_account, // 数据2
{
name: "数据1",
type: "line",
data: fundData.data,
color: "#FF7979",
symbol: false,
symbolSize: 0, // 拐点圆的大小
areaStyle: {
// 折线渐变阴影
color: new echarts.graphic.LinearGradient(0, 0, 0, 1, [
{
offset: 0,
color: "#FEE1E1"
},
{
offset: 0.76,
color: "#FFF8F8"
}
])
},
// 🔔重点看这🔔重点看这🔔重点看这
markLine: {
lineStyle: { width: 2 }, // 标线大小
symbol: "none", //去掉线最后面的箭头
data: [{
name: '水平线1',
yAxis: 1, // Y 值为给定值的标记线，用户自定义水平标线的值
lineStyle: { color: "#FFAE00" },
symbolKeepAspect: true, // 是否在缩放时保持该图形的长宽比
symbolRotate: 1, // 起点标记的旋转角度
symbolSize: [25, 25] // 起点标记的大小
},
{
name: '水平线2',
yAxis: 0.9, // Y 值为给定值的标记线，用户自定义水平标线的值
lineStyle: { color: "#FF4A00" },
symbolKeepAspect: true, // 是否在缩放时保持该图形的长宽比
symbolRotate: 1, // 起点标记的旋转角度
symbolSize: [25, 25] // 起点标记的大小
}
]
}
},
{
name: "数据4",
type: "line",
data: retracementData.data,
color: "#6C9EF8",
gridIndex: 1,
xAxisIndex: 1,
yAxisIndex: 1,
symbolSize: 0, // 拐点圆的大小
areaStyle: {
color: new echarts.graphic.LinearGradient(0, 0, 0, 1, [
{
offset: 0,
color: "rgba(115,156,250,0.05)"
},
{
offset: 0.76,
color: "rgba(115,156,250,0.25)"
}
])
}
}
]
};
